• CPU: Atmel AT91SAM9G45 ARM core processor @ 400MHz
• 128Mbyte SDRAM
• 256MB NAND FLASH
• TF card support
• RTC/Watchdog/Buzzer Support
• VGA, Ethernet, USB Host, Audio In/Out
• 4 x RS232, 3 x RS485, 1 x CAN bus, 4 LED
• Support expand more interface by custom design
• Support Linux 2.6.30 system(Telnet, NFS, TCP/IP support)
• Industrial standard: -40 ° C ~ +85 ° C

HardWare

• Full-featured PC, tiny and power saving
• Atmel AT91SAM9G45 ARM core processor @ 400MHz
• ARM926EJ-STM core with MMU capable
• 128Mbyte SDRAM
• 256MB NAND FLASH
• RTC: Battery backed Real Time Clock/Calendar
• Watch-Dog: On chip watch-dog timer
• Buzzer Support
• TF card slot: One TF card slot in  the case
• Display: One VGA interface, 800*600
• USB Host: two USB Host, 480Mhz
• Audio: One Audio In, One Audio Out
• RS232 Uarts: four RS232 Serial port
• RS485 Uarts: three RS485 Serial port
• CAN bus: One CAN bus
• LED: three User LED, 1 System LED
• Support expand more function by customs design(9 Serial port, GPIO interface)
• Electrical, Mechanical and Environmental Specifications
  • Supply Voltage: 12V/1A
  • Power Consumption: 1.4W - 3W, depending on CPU speed and slected features
  • Dimensions: 170 x 170 x 42mm
  • Operation temp(case): -40° to 85°C
  • Storage temperature: -40° to 85° C
